SIGMA FP
₨569,700
SKU: #C43900
- World’s smallest and lightest full-frame camera
- Robust & lightweight aluminum body
- Dust and splash proof structure
- Supports UHD 4K/24, 25 & 30 fps
- Supports 12-bit Cinema DNG
- Electronic image stabilization
- Full-time electronic shutter
- Face/Eye Detection AF
- HDR Shooting
Specification
| Type Interchangeable-lens Mirrorless Type Digital Camera |
| Memory Media SD, SDHC, SDXC memory card (UHS-II supported), Portable SSD (USB 3.0 connection, USB bus power supported) |
| Lens Mount L-Mount |
| Type 35mm full-frame (35.9mm x 23.9mm) Back-illuminated Bayer CMOS sensor |
| Camera Effective Pixels / Total Pixels Approx. 24.6 MP / Approx. 25.3 MP |
| Aspect Ratio 3:2 |
| Color Filter System RGB Primary color filter |
| Still Image File Format Lossless compression RAW(DNG) data 12 bit, 14 bit / JPEG(Exif2.3), RAW(DNG)+JPEG:recording is possible |
| Image Aspect Ratio [21:9] / [16:9] / [3:2] / [A Size (√2:1) ] / [4:3] / [7:6] / [1:1] |
| DC crop mode in ( ) |
| RAW HIGH: 6,000×4,000 (3,840×2,560) LOW: 3,008×2,000 (1,920×1,280) |
| JPEG [21:9] HIGH: 6,000×2,576 (3,840×1,648) MED: 4,240×1,824 (2,736×1,168) LOW: 3,008×1,288 (1,920×824) |
| JPEG [16:9] HIGH: 6,000×3,376 (3,840×2,160) MED: 4,240×2,392 (2,736×1,536) LOW: 3,008×1,688 (1,920×1,080) |
| JPEG [3:2] HIGH: 6,000×4,000 (3,840×2,560) MED: 4,240×2,832 (2,736×1,824) LOW: 3,008×2,000 (1,920×1,280) |
| JPEG [A Size (√2:1) ] HIGH：5,664×4,000 (3,616×2,560) MED：4,000×2,832 (2,560×1,824) LOW：2,832×2,000 (1,808×1,280) |
| JPEG [4:3] HIGH：5,344×4,000 (3,408×2,560) MED：3,776×2,832 (2,416×1,824) LOW：2,672×2,000 (1,712×1,280) |
| JPEG [7:6] HIGH：4,960×4,000 (3,184×2,560) MED：3,520×2,832 (2,272×1,824) LOW：2,480×2,000 (1,584×1,280) |
| JPEG [1:1] HIGH：4,000×4,000 (2,560×2,560) MED：2,832×2,832 (1,824×1,824) LOW：2,000×2,000 (1,280×1,280) |
| sRGB, Adobe RGB |
| Camera Internal Record |
| Movie Format CinemaDNG（8 bit, 10 bit, 12 bit）/ MOV：H.264 （ALL-I, GOP） |
| Audio Format Linear PCM (2 ch 48 kHz / 16 bit) |
| Record Format / Frame rate 3,840 x 2,160 (UHD 4K) / 23.98 p, 24 p, 25 p, 29.97 p 1,920 x 1,080 (FHD) / 23.98 p, 24 p, 25 p, 29.97 p, 48 p, 50 p, 59.94 p, 100 p, 119.88 p |
| Continuous Shooting Enable Time Up to 2 hours |
| Cinema DNG Memory Media Limitation SD Card (UHS-II): UHD 8 bit 25 p or less, FHD 12 bit 59.94 p or less Portable SSD: UHD 12 bit 29.97 p or less, FHD 12 bit 100 p or less, FHD 8 bit 119.88 p or less |
| HDMI External Output |
| Movie Format 4:2:2 8 bit 12 bit RAW: External recorder: ATOMOS Ninja V, Blackmagic Video Assist 12G supported |
| Audio Format Linear PCM (2 ch 48 kHz/16 bit) |
| Record Format / Frame Rate 4,096 x 2,160 (DCI 4K) / 24p *Only for RAW output 3,840 x 2,160 (UHD 4K) / 23.98p, 24p, 25p, 29.97p 1,920 x 1,080 (FHD) / 23.98p, 24p, 25p, 29.97p, 48p, 50p, 59.94p, 100p, 119.88p |
| AF System / Focus Mode Contrast detection system, Single AF, Continuous AF (with moving object prediction function), Manual Focus |
| AF Sensitivity Range / AF Mode -5 to 18 EV (F1.4:ISO 100) / Auto, 49-point selection mode, Free Move mode, Face/Eye Detection AF mode, Tracking AF mode |
| AF Lock Half-press the shutter button, or press the AEL button (setting change required) |
| Other Focus Functions AF+MF, MF Assist, MF Guide, Focus Peaking, Release Focus Function, AF-ON, Quick AF, Pre-AF, AF during Image Magnification |
| Metering System Evaluative, Spot, Center Weighted Average |
| Metering Range -5 to 18 EV (50mm F1.4:ISO 100) |
| Still Image Shooting Mode (P) Program AE (Program Shift capable), (S) Shutter Speed Priority AE, (A) Aperture Priority AE, (M) Manual |
| Movie Shooting Mode (P) Program AE, (S) Shutter Angle Priority AE, (A) Aperture Priority AE, (M) Manual |
| ISO Sensitivity (Recommended exposure value) |
| Base ISO [Still] ISO 100,640 [Cine] CinemaDNG 12 bit / HDMI RAW:ISO 100, 3200 MOV / CinemaDNG 10 bit, 8 bit, HDMI 4:2:2 8 bit:ISO 100, 640 |
| Settable Range ISO 100-25600 / Expanded sensitivity ISO 6, 12, 25, 50, 51200, 102400 |
| Exposure Compensation ±5 EV (in 1/3 stop increments) : ±3 EV at movie recording |
| AE Lock Half-press the shutter button, or press the AEL button (setting change required) |
| Exposure Bracket 3 shots / 5 shots stage exposure 3EV (1/3 Step, Standard→Underexposure→Overexposure) (Sequence changeable) |
| Electronic Image Stabilization System (EIS) |
| 12 types (Auto, Auto [Lighting Source Priority], Daylight, Shade, Overcast, Incandescent, Fluorescent, Flash, Color Temperature [50K steps], Custom 1, Custom 2, Custom 3) |
| Shutter Type Electronic shutter |
| Shutter Speed 30 to 1/8,000 sec., Bulb up to 300 sec. *Up to 1/4,000 sec. when using electronic image stabilization |
| Self Timer 2 sec. / 10 sec. |
| Drive Modes Single Capture, Continuous, Self Timer (2 sec. / 10 sec.), Interval Timer |
| Continuous Drive Speed High Speed: approx. 18 shots/ sec, Medium Speed: approx. 5 shots/ sec, Low Speed: approx. 3 shots/ sec. |
| Number of Recordable Frames HIGH: 12 frames, MED: 12 frames, LOW: 24 frames |
| Type / Coverage TFT color LCD, Aspect Ratio 3:2, 3.15 type, Approx. 2.1M dots, Electrostatic capacitance system touch panel / Approx. 100% |
| Built-in Flash None |
| Flash Mode S-TTL automatic light control, Manual, Wireless flash, Multi-emission |
| Optional Functions Red-eye Reduction / Slow Synchronization, Rear Curtain Synchronization |
| Flash Exposure Compensation Max. ±3 EV in 1/3EV step increments |
| Flash Sync. Speed Max. 1/30 sec. * 1/15 sec. or less at 14 bit RAW |
| External Flash Support Available when the HOT SHOE UNIT HU-11 (supplied with this product) is mounted. *S-TTL, Wireless support, X-sync. |
| 15 types (Standard, Vivid, Neutral, Portrait, Landscape, Cinema, Teal and Orange, Sunset Red, Forest Green, Powder Blue, FOV Classic Blue, FOV Classic Yellow, Duotone, Monochrome, Off) |
| Supported cameras |
| ARRI ARRICAM / ARRIFLEX, ALEXA LF/ ALEXA Mini LF, ALEXA SXT, ALEXA Mini, AMIRA, ALEXA65, ALEXA XT |
| SONY VENICE |
| RED MONSTRO 8K, HELIUM 8K, DRAGON 6K, EPIC MX 5K, GEMINI 5K, KOMODO 6K |
| Frame Guide 1.33:1, 1.85:1, 2.39:1, Custom 1, Custom 2 |
| Custom Frame Input (Sensor Area / Aspect Ratio), Offset, Style (4 styles), Line (1 to 10 px), Color (White, Black, Red, Yellow, Green, Cyan, Blue, Magenta), Shading |
| Save / Load Settings via QR code, Screenshot, Webcam, In-camera RAW development, Still image capture from recorded movie files, Cinemagraph, Fill Light, HDR shooting (Still / Cine), Still image shooting during movie shooting |
| Built-in stereo microphone, Monaural speaker |
| English / Japanese / German / French / Spanish / Italian / Simplified Chinese / Traditional Chinese / Korean / Russian / Dutch / Polish / Portuguese / Danish / Swedish / Norwegian / Finnish |
| USB Terminal USB3.1 GEN1 Type-C (supports Mass Stroage, Video Class(UVC), Camera Control) |
| HDMI Terminal Type D (Ver.1.4) |
| Remote Also used as an external microphone terminal |
| Timecode Input Also used as an external microphone terminal |
| External Microphone Terminal ø3.5mm stereo mini jack (Plug-in power support) |
| Headphone Output Terminal ø3.5mm stereo mini jack (can be connected when using the dedicated ELECTRONIC VIEWFINDER EVF-11) |
| Flash-synchro Terminal Dedicated terminal (with HOT SHOE UNIT HU-11 (supplied with this product) mounted) |
| Dust and Splash Resistant Structure provided (Although this construction allows the lens to be used in light rain, it is not the same as being waterproof.) |
| Li-ion Battery Pack BP-51 *Internal battery charge via USB terminal available. (the camera can not be used while charging) |
| Dimensions (W x H x D) 112.6 x 69.9 x 45.3mm / 4.4 x 2.8 x 1.8 in. |
| Weight 422 g / 14.9 oz. (including battery and SD card), 370 g / 13.0 oz. (camera body only) |
| Operating Temperature 32 – 104 °F / 0 – +40 °C |
| Operating Humidity 85% or less (non-condensing) |
| Li-ion Battery Pack BP-51, Strap, STRAP HOLDER SH-11, USB AC ADAPTER UAC-11, USB CABLE (A-C) SUC-11, HOT SHOE UNIT HU-11, Body Cap, Instruction Manual |
